LEVs Specification
VEHICLE PARAMETERS
Vehicle size1880×720×1160mm
Wheelbase1330mm
Min ground clearance200mm
Seat height880mm
Vehicle weight74kg(without battery)
Loading200kg
Top Speed100km/h
Battery Range
90km(A verage Speed 35-45km/h),load 75kg
Break formCBS brakes
Tyre (Fr/Rr)
Front(110-70/12),Rear(110-70/12)
DisplayLCD
HeadlightsLED
MAIN TECHNICAL PARAMETERS OF BATTERIES
BatteryLithium battery
Battery capacity30AH(Single battery)
Battery voltage72V
Battery weight21kg
BATTERY SWAPPING SYSTEM/CHARGER
Charger specificationsFixed battery system
MAIN TECHNICAL PARAMETERS OF MOTOR
Motor model
Permanent magnet synchronous motor
Power6000W
Maximum speed
Rated voltage72V
Slope Hill-ability≤30°
Gear speed3
First gear50km/h
Second gear70km/h
Third gear100km/h
Packing
PackingTwo layers of full cardboard box, three layers of iron
frame and cardboard box
Packing size
