LEVs Specification
VEHICLE PARAMETERS
Vehicle size1780×720×1160mm
Wheelbase1250mm
Min ground clearance200mm
Seat height850mm
Vehicle weight52kg(without battery)
Loading
200kg(including vehicle weight)
Top Speed75km/h
Battery Range80km/125km
Break form
Front and Rear Disc Brake(CBS)
Tyre (Fr/Rr)3.0-10
DisplayLCD
HeadlightsLED
MAIN TECHNICAL PARAMETERS OF BATTERIES
BatteryLithium battery
Battery capacity35AH
Battery voltage72V
Battery weight15kg
BATTERY SWAPPING SYSTEM/CHARGER
Charger specificationsSwappable battery system
MAIN TECHNICAL PARAMETERS OF MOTOR
Motor model
Permanent magnet synchronous motor
Power3000W
Maximum speed
Rated voltage72V
Slope Hill-ability30°
Gear speed3
First gear30km/h
Second gear50km/h
Third gear75km/h
Packing
PackingTwo layers of full cardboard box, three layers of iron
frame and cardboard box
Packing size
