LEVs Specification
VEHICLE PARAMETERS
Vehicle size1940×720×1100mm
Wheelbase1340mm
Min ground clearance150mm
Seat height760mm
Vehicle weight86kg(without battery)
Loading150kg total
Top Speed80km/h
Battery Range80km/160km(two batteries)
Break formFront and Rear CBS brakes
Tyre (Fr/Rr)Fr100/80-14 Rr120/70-14
DisplayLCD instrument panel
HeadlightsLED lighting
MAIN TECHNICAL PARAMETERS OF BATTERIES
BatteryLithium battery (Dual battery)
Battery capacity35×2AH
Battery voltage72V
Battery weight15×2kg
BATTERY SWAPPING SYSTEM/CHARGER
Charger specificationsSwapping battery system
MAIN TECHNICAL PARAMETERS OF MOTOR
Motor modelHub
Power4000W
Maximum speed850r/min
Rated voltage72V
Slope Hill-ability18°
Gear speed
First gear45km/h
Second gear60km/h
Third gear80km/h
Packing
PackingTwo layers of full cardboard box, three layers of iron
frame and cardboard box
Packing size1700mm×560mm×870mm
ColorRed/Blue/Grey/White/Black
