LEVs Specification
VEHICLE PARAMETERS
Vehicle size1930×700×1120mm
Wheelbase1430mm
Min ground clearance200mm
Seat height900mm
Vehicle weight90kg(without battery)
Loading150kg
Top Speed100km/h
Battery Range
90km(A verage Speed 35-45km/h),load 75kg
Break formCBS brakes
Tyre (Fr/Rr)
Front(130/70-13),Rear(130/70-12)
DisplayLCDl
HeadlightsLED
MAIN TECHNICAL PARAMETERS OF BATTERIES
BatteryLithium battery
Battery capacity35AH×2
Battery voltage73V
Battery weight15kg
BATTERY SWAPPING SYSTEM/CHARGER
Charger specificationsSwappable battery system
MAIN TECHNICAL PARAMETERS OF MOTOR
Motor modelHub motor
Power3000W
Maximum speed
Rated voltage73V
Slope Hill-ability≤30°
Gear speed3
First gear45km/h
Second gear70km/h
Third gear100km/h
Packing
PackingTwo layers of full cardboard box, three layers of iron
frame and cardboard box
Packing size1700mm×560mm×870mm
